LS225 with F500 Plating Thickness Gauge

LS225 with F500 Plating Thickness Gauge

670.00 - 720.00 USD ($)/Set

Product Details:

  • Size 148x76x26mm
  • Weight 275 Grams (g)
  • Width 76 Millimeter (mm)
  • Color White
  • Product Type Plating Thickness Gauge
  • Height 26 Millimeter (mm)
  • Length 148 Millimeter (mm)
  • Click to View more

Price And Quantity

  • 1 Unit
  • 670.00 - 720.00 USD ($)/Set

Product Specifications

  • 26 Millimeter (mm)
  • 0.0-500μm
  • Industrial
  • 148 Millimeter (mm)
  • Other
  • Color Measurement And Color Comparison
  • 275 Grams (g)
  • 148x76x26mm
  • Plastic
  • White
  • 76 Millimeter (mm)
  • Plating Thickness Gauge

Trade Information

  • Hong Kong
  • 1000 Unit Per Month
  • 15 Days
  • Contact us for information regarding our sample policy
  • LS225+F500 Plating thickness gauge*1 F500 probe*1 Fe zero-adjustment plate*1 Standard films*1 User manual*1 Certificate / Warranty card*1 1.5V AAA alkaline battery*1 Plastic engineering case*1
  • Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
  • All India
  • LS225+F500 plating thickness gauge conforms to the following standards: GB/T 4956-2003 Non-magnetic Coatings on Magnetic Substrates-Measurement of Coating Thickness-Magnetic Method DIN EN ISO 2808 Paints and Varnishes-Determination of Film Thickness JJG-818-2005 Verification Regulation of Magnetic and Eddy Current Measuring Instrument for Coating Thickness

Product Description

Ultra small objects can be measured easily

LS225 with F500 plating thickness gauge use F500 ultra small probe, which is especially suitable for measuring coatings on small workpieces such as screws and bolts

Advanced technology ensures measurement accuracy and the ability to measure ultra thin coatings

The probe adopts digital oscillation technology and high speed ADC acquisition to ensure the high stability of the plating thickness gauge,It can measure ultra thin coatings

Conforms to national and international standards, Pass the inspection of Chinese authoritative metrology agencies

Using advanced digital probe technology, digital signal processing is done directly inside the probe. The probe is not easily interfered and provides excellent measure accuracy. The temperature change does not affect the measurement and the data remains stable to ensure very good repeatability which guarantees to pass the inspection of Chinese authoritative metrology agencies

Continuous measurement support

LS225 with F500 coating thickness gauge can continuously takes measurements which is ideal for analyzing large areas and gets one measurement result in 0.4 seconds

Multiple Calibration adjustment options including 1 to 5 points

Plating Thickness Gauge supports zero adjustment and multi point calibration, up to 5 point. It is equipped with 7 pieces of standard films of different thicknesses. The curve can be modified according to the standard film or the actual workpiece to make the measurement data more accurate

Powerful data statistics function

With data statistics function, it can store up to 9 measurement values. The plating thickness gauge can automatically calculate the maximum, minimum, average and standard deviation of the measured data

Hard probe

The hard probe ensures long term effective use of the instrument

Fixture optional, Measurement stable

Dedicated stable fixtures are provided for users to purchase, which can make the measurement more convenient and eliminate the measurement errors caused by human factors
