LS117 Optical Density Meter

LS117 Optical Density Meter

870.00 - 900.00 USD ($)/Set

Product Details:

  • Product Type Optical Density Meter
  • Width 76 Millimeter (mm)
  • Height 26 Millimeter (mm)
  • Length 148 Millimeter (mm)
  • Weight 576 Grams (g)
  • Color Black
  • Size 148x76x26mm
  • Click to View more

Price And Quantity

  • 10 Unit
  • 870.00 - 900.00 USD ($)/Set

Product Specifications

  • Optical Density Meter
  • 26 Millimeter (mm)
  • 4 AAA alkaline dry batteries
  • 76 Millimeter (mm)
  • Plastic
  • Digital Only
  • 5 Volt (V)
  • 148 Millimeter (mm)
  • 148x76x26mm
  • Black
  • 576 Grams (g)
  • Industrial

Trade Information

  • Hong Kong
  • 1000 Unit Per Month
  • 5 Days
  • Contact us for information regarding our sample policy
  • LS117 Optical Density Meter*1 AAA battery*1 User Manual*1 Certificate / warranty card*1 Aluminum box*1 Packing box dimension 34*25*14 cm(L*W*H)*1
  • Asia Australia Central America South America Western Europe Middle East Eastern Europe North America Africa
  • All India
  • The LS117 Optical Density Meter conforms to the following standards: JJF1225-2009 Calibration Specification for Transmittance Meter of Automobile JJG920-2017 Diffuse Transmission Visual Densitometers

Product Description

High resolution, wide optical density measurement range

The optical density meter has wide measuring range. The optical density value can be measured to OD 6. The transmittance resolution is up to 0.005%

Light transmittance and optical density are measured simultaneously

During the test, the interface displays both the transmittance value and the optical density value of the material

Diffuse transmission light path design

The LS117 portable densitometer uses a diffuse transmission light path design, which has the same effect of the integrating sphere. There are relevant instructions in GB / T 11500-2008 / ISO 5-2: 2001. The regulation has stated that Use opale glass method instead of integrating sphere method as the basis of ISO standard diffuse transmission density

High-precision and great accuracy

The light source complies with the CIE photopic luminosity function to ensure that it passes the testing of the Chinese Metrology Institute

The optical density meter has two measurement methods which is more flexible to use.

Fixed measurement: It is more suitable for testing regular or smaller objects.

Hand-held measurement: take the probe down for testing, which is more suitable for irregular and large-volume materials
